Please make sure that the power voltage being used matches with the supply voltage of gate opener (AC110V or AC220V); kids are not allowed to touch the control devices or the remote-control unit.
The remote-control unit is single button mode or three button mode (please refer to the instructions for the remote control in accordance with the actual gate opener type). The indicator light on the remote-control unit will flicker when its button is pressed. Main engine and gate can be unlocked with a disengagement wrench and the gate can be manually operated after disengagement. Please make sure that nobody is around the main engine or gate when the switch is operated.
Please temporarily stop using the product if the main engine needs to be repaired or regulated. The installation and maintenance of the product must be carried out by professionals.
Please read this manual carefully before installing、using、maintaining or repairing it. Without following this manual, any injury or property losses caused by improper use or unauthorized modification is out of the responsibility of our company.
| Model || SWG4000 || SWG4001 |
|Power supply ||AC220V/50Hz||AC110V/60HZ|
|Maximum weight of single gate||400Kg||≥30m|
|Distance for remote control||≥30m||≥30m|
|Remote control mode||Single-button mode/Four-button mode||Single-button mode/Four-button mode|
|Limit switch||Mechanical limit switch||Mechanical limit switch|
|Working duty||S2, 15min||S2, 15min|
|Recording of up remote controls||25||25|
|Frequency||433.92 MHz||433.92 MHz|
|Working temperature||-20°C ~ +70°C||-20°C ~ +70°|
