Rolling shutter motor control board RS0103

Rolling shutter motor control board RS0103

Adjustment soft start and soft stop rolling shutter control board

  • Item No.RS0103
    MOQ60 PCS
  • Product size13 x 13 x 16.5 cm
    Product weight201 g
  • CTN. Spec 40.5*45.5*25 cm / 60PCS
    G.W/N.W12 / 9.6 kg
Trade Assuranceprotects your orders
On-time Dispatch Guarantee
On-time dispatch is guaranteed or you will be eligible to claim platform compensation.
Refund Policy
If the shipment is delayed or product quality differs from what are specified in the online order, you can claim for a refund.
Quick refund: If you can apply for a refund within two hours of making a payment, you will receive a refund immediately.

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Rolling shutter motor control board RS0103

I.Technical parameters
1. Working voltage: 24V AC
2. Temperature range:-20℃ to 60℃
3. Loading capacity:100W, 24VDC
4. Built-in fuse: motor (10A), electric circuit (0.5A). please exchange appropriate fuse according to loading capacity
5. Working frequency: 433.92MHz
6. Stored transmitters: 30pcs

II.Safety Instruction
1. For security, please read instructions carefully before initial operation; making sure that the power is off before   connection.
2. Please clear the memory before initial operation. (Ref: Erasing ALL learned/memorized Transmitters)
3. Do not learn the remote control when motor is operating in order to avoid mis-operation.
4. The received signal may be interfered by other communication devices. (e.g. the wireless control system with   the same frequency range)
5. It is forbidden to control the high-risk coefficient equipment / system. (e.g. cranes)
6. It is used only for the manual remote control and wireless control equipment / system which must not endanger life or property during running failure, or its security risks have been eliminated
7. It should be applied in dry indoor place or in the electric appliance place.

HILAND TECHNOLOGY
19 YEARS EXPERIENCE WITH HIGH QUALITY ASSURANCE
Established in March, 2004, Zhejiang Hiland Technology Co., Ltd is a professional designer and qualified manufacturer for automatic control systems. Hiland serve programmable wireless transmitter, sliding gate opener, receiver, tubular motor receiver, sliding gate control board, roller shutter control board, flash lamp, photocell and wireless keypad. Hiland brand products with unique design have been approved by ISO9001-2008, CE(EMC,LVD,RF), C-TICK, EN12978, RoHS ,etc. strict requirements, and sell well in Europe, Asia, Middle east, North America, etc.Hiland have improved SAMSUNG SMT machine and soldering machine, ICT test, FCT test to guarantee PCBA with high quality.
