Sliding gate control board SL1800

Sliding gate control board SL1800

Wholesale soft start and soft stop sliding door control PCB board

  • Item No.SL1800
    MOQ40 PCS
  • Product size16.2 x 8.5 x 4 cm
    Product weight387.9 g
Trade Assuranceprotects your orders
On-time Dispatch Guarantee
On-time dispatch is guaranteed or you will be eligible to claim platform compensation.
Refund Policy
If the shipment is delayed or product quality differs from what are specified in the online order, you can claim for a refund.
Quick refund: If you can apply for a refund within two hours of making a payment, you will receive a refund immediately.

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Product details
Auto close time 5/10/30S changable
Auto reverse when meet obstacle No
Build-in fuse Electric circuit(0.5A); Motor(10A), pls exchange approprite fuse according to loading capacity
CertificationCE
Code Rolling code
Electric lock Yes
External switch one button& three button Both
Frequency433.92MHz/318MHz/315MHz
Installation at left or right side Yes
Loading capacity 1 HP 220VAC
Product size 155*77*38mm
Product weight 333g
Resistance of opening and closing door No
Running time 5-100S adjustable
Self-learning function Yes
Soft start soft stop Yes
Transmitters stored 30
Voltage output AC24V
Working temperature -20℃ to 60℃
Working voltage 220VAC, 50Hz

Packaging & Delivery

Selling Units:
PCS
Single package size:
16.2 x 8.5 x 4 cm
Single gross weight:
387.9 g

Sliding gate control board SL1800

I. Safety Instruction

1.1 For security, please read instructions carefully before initial operation; making sure that the power is off before connection.
1.2 Please clear the memory before initial operation. (Ref.: Erasing ALL learned/memorized Transmitters)
1.3 Do not learn the remote control when motor is operating in order to avoid mis-operation.
1.4 The received signal may be interfered by other communication devices. (e.g. the wireless control system with the same frequency range)
1.5 It is used only for the manual remote control and wireless control equipment / system which must not endanger life or property during running failure, or its security risks have been eliminated.
1.6 It should be applied in dry indoor place or in the electric appliance place.

II. Technical Index

2.1 Working voltage: 220VAC/110VAC,50Hz/60Hz
2.2 Temperature range: -20℃ to 60℃
2.3 Loading capacity : 1 HP 220VAC ; 0.5 HP 110VAC
2.4 Built-in fuse: electric circuit(0.5A); Motor(10A),Please exchange appropriate fuse accoding to loading capacity
2.5 Time of soft-start : 1S ; soft-stop: 1S/2S/3S are optional
2.6 Running time: Adjustable from 5s to 100s ----S4 is to set up
2.7 Frequency: 433.92MHz
2.8 Transmitter stored: 30PCS
2.9 Output voltage: AC24V
2.10 Output with electric lock: normally-closed contact
2.11 Output with flash lamp: AC220V/AC110V
2.12 External switch (open,stop,close in a loop)
2.13 External limit ( DIP8 to select NO and NC)
2.14 External infrared (NC contact)
2.15 Auto close time is adjustable: (5S,10S,30S are optional by using DIP1,DIP2)
2.16 Soft start function is optional by  DIP5
2.17 Installation at left or right side is optional by DIP6.
2.18 Single / three button control is optional by DIP7
2.19 Size: 155*77*38mm
