Door battery type photocell with 2 years battery life P5112
Battery inside automatic gate control photocell P5112
Packaging & Delivery
-
Product size
14 x 11.5 x 3.5 cm
-
Product weight
300 g
-
CTN. Spec
38*20*20 cm / 40Set
-
G.W/N.W
13 / 10 kg
-
Certification
12-24VAC/DC or 1.5V, 2 x LR6 AA size battery
-
Color
Dark purple
-
Product weight
220g
-
Loading capacity
1A/30VDC
-
Working temperature
-20℃ to 60℃
-
Wavelength
940nm
-
IP Level
IP54
-
Working current
Emitter: ≤8mA receiver: ≤40mA
-
Angle of opposite emission
≤±5°
-
Receiver range
≥12m
I. Safety Instruction
1. For security, please read the user manual carefully before initial operation;
2. This photocell is without any fuse, so Please make sure the power is off before installation;
3. Only used this system that do not cause any danger life or property during the running failure or its security eliminated;
4. Please guarantee the products used in effective working range.
II. Technical Specification
1.Working voltage: Receiver: 12~24VAC/DC Emitter: 2*1.5V, LR6 AA battery
2.Working current: Receiver(24VDC): ≤40mA Emitter(2*1.5V, LR6 AA battery): ≤0.2mA
3.Photocell wavelength: 940nm
4.Angle of opposite emission: ≤±5º
5.Receiver range: ≥12m
6.Working temperature: -20º～+60℃
7.Relay contact loading capacity: 1A/30VDC
8.Waterproof grade: IP45
9.Size: 127*50*35mm
10.Weight：193g
